SuperK SELECT

SuperK SELECT – tunable multi-channel filter

The SuperK SELECT is a multi-channel tunable filter based on Acousto-Optic Tunable Filter technology (AOTF). You get access to up to eight simultaneous, freely tunable channels. It is an easy-to-use, flexible, and accurate tuning accessory that provides access to any wavelength in the SuperK spectrum, from 400-2400 nm.

We have designed it for industrial use. Its robust and compact design gives you maintenance-free 24/7 operation.

Key Features

400-2400 nm tuning range

16 simultaneous, tunable channels

Dual VIS/nIR, nIR/IR port access

Robust and maintenance-free

Easy connection to SuperK lasers

Simple user interface via CONTROL

Filter configurations

AOTF1/AOTF2VIS-nIR
(500-900nm)
nIR1
(640-1100nm)
nIR2
(800-1400nm)
IR
(1100-2000nm)
 UV-VIS
(400-650nm)
400-650nm /
690-900nm
400-650nm /
690-1100nm
400-650nm /
800-1400nm
400-650nm /
1100-2000nm
VIS (1x)
(430-700nm)
430-665nm /
690-1100nm
430-700nm /
800-1400nm
430-700nm /
1100-2000nm
VIS (4x)
(450-700nm)
450-665nm /
690-1100nm
450-700nm /
800-1400nm
450-700nm /
1100-2000nm
VIS-nIR
(500-900nm)
500-850nm /
900-1400nm
500-900nm /
1100-2000nm
nIR1
(640-1100nm)
640-1100nm /
1200-2000nm
nIR2
(800-1400nm)
800-1100nm /
1200-2000nm

Want to know more?

Get in touch with one of our supercontinuum experts

For our PhotoVivo platform, we use the SuperK FIANIUM with SuperK accessories. We can now measure optical coefficients of ex vivo biological tissues, synthetic materials, i.e. optical phantoms in the 380-2000 nm range.

M. Amouroux and the CRAN team CRAN, Université de Lorraine – CNRS

Tunable filtering and built-in intelligence

Tunable filtering over two octaves

The SuperK SELECT is equipped with one or two Acousto-Optic Tunable Filters (AOTF), powered by an RF driver.

The AOTFs allow tunable filtering over two octaves in the visible, nIR, or IR spectra. Each octave has its own optical output. Choose from the standard free-space collimated beam or the optional fiber-delivered output.

Up to 8 wavelengths

Up to 8 wavelengths per channel can be continuously tuned simultaneously for each AOTF and the power of each wavelength can be controlled through the CONTROL software as well.

Built-in intelligence lets you plug and play

Intelligent SuperK accessories communicate with the SuperK FIANIUM via the specially designed communication bus. No need for complicated downloads or configurations. Just plug the accessories in and let the SuperK recognize and install them.

Additional accessories? No problem! The external bus can handle the connection of multiple accessories, so you can expand the uses of the SuperK without any fuss.

The CONTROL software gives you access to all information about the status of SuperK SELECT.

LEDs on the side panel can inform you about shutter position (Emission), Interlock, applied RF signal, and the supply voltage via the external bus.

The SELECT has a built-in RF switch that lets you switch between the two AOTFs without cable changes.

Options

Power lock, external power stabilization

The Power Lock options enable you to lock the power output of the SuperK SELECT via a build-in photodetector. Simply connect the detector to the External Feedback BNC connector of the SuperK. Activate locking from the control panel and the SuperK will now lock the power output of the SELECT.

Power Lock monitors are available for both output ports. The long-term stability of a locked output will typically be better than +/- 0.5 % (over many hours) – depending on the wavelength.

Get more information in our application note: SuperK Power Lock and modulation

Single-mode fiber delivery

The SuperK SELECT is compatible with our SuperK CONNECT high-performance fiber delivery system that comes complete with broadband fibers and a range of termination options such as FC/PC connectors or high-quality collimators.

Interfacing is handled by the CONNECT fiber coupling block that ensures easy and stable single-mode coupling that can be disconnected and reconnected without alignment.

SuperK SELECT multi-channel tunable filter

Specifications

Choose model:
SELECT
Number of tunable channels
1-8 per AOTF
Filter bandwidth (UV-VIS)1)
1.8-8.5 nm
Filter bandwidth (VIS 1x)1)
0.5-1.85 nm
Filter bandwidth (VIS 4x)1)
2.5-8.5 nm
Filter bandwidth (VIS-nIR)1)
3.5-14 nm
Filter bandwidth (nIR1)1)
1.8-5 nm
Filter bandwidth (nIR2)1)
2.6-9.6 nm
Filter bandwidth (IR)1)
6.4-19.8 nm
AOTF deflection efficiency
> 90% (1-8 channel operation)
Polarization2)
Linear
Output mode
Fiber or free-space collimated

1) Collimated free-space output, FWHM bandwidth.

2) Horizontal with respect to the base.

SELECT
Operation temperature
+15o to +30oC
Storage temperature
+5o to +50oC
Humidity, non-condensing
20-80% RH
Dimensions (WxHxL)
195 x 67.6 x 195 mm
Weight
≈4 kg
SELECT
Mechanical shutter
Integrated for both ports
Laser safety interlock
Integrated
